材料及表面处理
螺纹本体 | 锁紧螺母 | 销头 | 把手 | 把手套 |
黑色氧化钢 | 黑色氧化钢 | 精车氮化钢 | 黑色氧化钢 | 高弹性PA |
另有同规格不锈钢款可供选择，详情请联系我司营业人员
| 零件号 | 规格 | d1 | d2 | d3 | l1 | l2 | l3 | l5 | 预压[N] | 最大压载[N] | 重量[g] |
| EV272-03140001 | B型 | 5 | M12 | 12 | 47 | 8 | 26 | 32 | 9 | 21 | 20 |
| EV272-03140002 | 6 | M12 | 12 | 47 | 8 | 26 | 32 | 9 | 21 | 29 | |
| EV272-03140003 | 6 | M16 | 16 | 56 | 10 | 30 | 42 | 12 | 32 | 30 | |
| EV272-03140004 | 8 | M12 | 12 | 47 | 8 | 26 | 32 | 9 | 21 | 39 | |
| EV272-03140005 | 8 | M16 | 16 | 56 | 10 | 30 | 42 | 12 | 32 | 60 | |
| EV272-03140006 | 8 | M20 | 20 | 69 | 12 | 36 | 52 | 21 | 58 | 120 | |
| EV272-03140007 | 10 | M16 | 16 | 56 | 10 | 30 | 42 | 12 | 32 | 63 | |
| EV272-03140008 | 10 | M20 | 20 | 69 | 12 | 36 | 52 | 21 | 58 | 120 | |
| EV272-03140009 | 12 | M20 | 20 | 69 | 12 | 36 | 52 | 21 | 58 | 120 | |
| EV272-03140010 | 5 | M12x1.5 | 12 | 47 | 8 | 26 | 32 | 9 | 21 | 28 | |
| EV272-03140011 | 6 | M12x1.5 | 12 | 47 | 8 | 26 | 32 | 9 | 21 | 61 | |
| EV272-03140012 | 6 | M16x1.5 | 16 | 56 | 10 | 30 | 42 | 12 | 32 | 101 | |
| EV272-03140013 | 8 | M12x1.5 | 12 | 47 | 8 | 26 | 32 | 9 | 21 | 30 | |
| EV272-03140014 | 8 | M16x1.5 | 16 | 56 | 10 | 30 | 42 | 12 | 32 | 63 | |
| EV272-03140015 | 8 | M20x1.5 | 20 | 69 | 12 | 36 | 52 | 21 | 58 | 113 | |
| EV272-03140016 | 10 | M16x1.5 | 16 | 56 | 10 | 30 | 42 | 12 | 32 | 66 | |
| EV272-03140017 | 10 | M20x1.5 | 20 | 69 | 12 | 36 | 52 | 21 | 58 | 116 | |
| EV272-03140018 | 12 | M20x1.5 | 20 | 69 | 12 | 36 | 52 | 21 | 58 | 122 | |
| EV272-03140019 | BK型 | 5 | M12 | 12 | 47 | 8 | 26 | 32 | 9 | 21 | 36 |
| EV272-03140020 | 6 | M12 | 12 | 47 | 8 | 26 | 32 | 9 | 21 | 37 | |
| EV272-03140021 | 6 | M16 | 16 | 56 | 10 | 30 | 42 | 12 | 32 | 78 | |
| EV272-03140022 | 8 | M12 | 12 | 47 | 8 | 26 | 32 | 9 | 21 | 38 | |
| EV272-03140023 | 8 | M16 | 16 | 56 | 10 | 30 | 42 | 12 | 32 | 78 | |
| EV272-03140024 | 8 | M20 | 20 | 69 | 12 | 36 | 52 | 21 | 58 | 150 | |
| EV272-03140025 | 10 | M16 | 16 | 56 | 10 | 30 | 42 | 12 | 32 | 81 | |
| EV272-03140026 | 10 | M20 | 20 | 69 | 12 | 36 | 52 | 21 | 58 | 156 | |
| EV272-03140027 | 12 | M20 | 20 | 69 | 12 | 36 | 52 | 21 | 58 | 153 | |
| EV272-03140028 | 5 | M12x1.5 | 12 | 47 | 8 | 26 | 32 | 9 | 21 | 35 | |
| EV272-03140029 | 6 | M12x1.5 | 12 | 47 | 8 | 26 | 32 | 9 | 21 | 41 | |
| EV272-03140030 | 6 | M16x1.5 | 16 | 56 | 10 | 30 | 42 | 12 | 32 | 63 | |
| EV272-03140031 | 8 | M12x1.5 | 12 | 47 | 8 | 26 | 32 | 9 | 21 | 79 | |
| EV272-03140032 | 8 | M16x1.5 | 16 | 56 | 10 | 30 | 42 | 12 | 32 | 81 | |
| EV272-03140033 | 8 | M20x1.5 | 20 | 69 | 12 | 36 | 52 | 21 | 58 | 109 | |
| EV272-03140034 | 10 | M16x1.5 | 16 | 56 | 10 | 30 | 42 | 12 | 32 | 145 | |
| EV272-03140035 | 10 | M20x1.5 | 20 | 69 | 12 | 36 | 52 | 21 | 58 | 151 | |
| EV272-03140036 | 12 | M20x1.5 | 20 | 69 | 12 | 36 | 52 | 21 | 58 | 157 |
